The Peaks-eco FDY 1250 F with two or more main Motors series is the largest in the range and is for the very large processing sites requiring high output and produces bales of up to 2000kg, with adjustable size and options include 200 or 300 tonnes.
The Peaks-eco FDY 1250 F Auto Tie Baler Machine with two or more main Motors series is the largest in the range and is for the very large processing sites requiring high output and produces bales of up to 2000kg, with adjustable size and options include 200 or 300 tonnes.
It is available with Horizontal Wire Tie design, with many different designs and feeding configurations available to suit each individual End User.
Automatic operation
Horizontal wire tie system
Extremely large hopper and feed opening
Variable bale length
High compaction force
Easy to use touch screen controls
Options for 200 and 300 tonnes pressing force
20 to 40 tonnes per hour
Easily processes a range of materials, including: cardboard, paper, trim, paper offcuts, plastic film and beverage containers
Suits a range of different Industries, including: Industry, Manufacturing, Print, Packaging, Retail, Logistics, Distribution, Recycling Centres, Materials Recovery Facilities (MRF’s), Waste Transfer Stations
Configuration and processing options are numerous and these can be developed to suit your specific feeding applications to ensure optimum throughput, ideal for processing recyclable volumes and fed continuously. Different options typically include by Conveyor (belt and steel slat) feed options, mobile equipment or a potential combination of these solutions.
Various design options are available to suit specific suite requirements, such as hydraulic shear de-blocker, perforator on hydraulic slide system and numerous customisable bale take off options to suit site layouts.
Parameters of 1250 F Double motor with two pump waste paper baler machine (Lengthen type) | ||||||
1 | Main cylinder | Mode | Φ280 | Travel | 2700mm | Homemade cylinder |
Nominal force | 1500KN | Amount | 1 set | |||
2 | Side plate of main cylinder | 12# | ||||
3 | Pressure of hydraulic system | 1600KN | ||||
4 | Feed Opening size | 1100*2000mm | ||||
5 | Bale size | 1100*1250*L(adjustable:1500-2000) | 5 lines | |||
6 | Bale density | 500kg/m³ | ||||
7 | Main engine power | 37KW+5.5KW+4.0KW+45KW | ||||
8 | Power supply specification | 30m²soft copper | ||||
9 | Packaging line | 12# iron wire | ||||
10 | Operation Way | Manual operation / linkage | ||||
11 | Cooler | 8 m²/10m² | ||||
12 | Production efficiency | 18-25bales/hour | ||||
13 | Hydraulic pump mode | Plunger pump 250ml/r*1 Gear pump 25ml/r*1 Vane Pump 5038 | FWD | |||
14 | Capacity of Fuel tank | 1.5 m³ | ||||
15 | Conveyor | W 2*10.5m | ||||
Tags: auto tie baler machine, automatic baler, automatic baling machine
